| lithium battery charger 12.6v 1a for 11.1v battery |
| Item No.: IN1262000 |
|
|
| Features/ Functions |
|
Smart 3 stage lithium battery charger
Constant charging current for fast charge
Terminate charge once battery is full
LED indicate the charge status
Standard approvals: GS CE BS EMC
Dongguan Shijie Intai Switching Power Supply Factory is a professional manufacturer of battery chargers |
|
|
|
 |
|
|
| General Specifications |
|
Input :100-240VAC, 50/60Hz
Output voltage : 7.5 ～12.6VDC
Output current : 1A +/-0.1A
No load standby power ≤0.5W
Efficiency: 80% Min.
Operating temperature: -29℃～+45.5℃
Storage temperature: -40℃～+75℃
Operating relative humidity: 5%～95% RH
Over load protection: Auto recovery
Short circuit protection: Auto recovery
MTBF: 30000 hours full rated load operation at 25℃
Inspection: MIL-STD-105D II AQL:CRI 0; MAJ 0.25; MIN 2.5
Warranty: 3 year
|
|
|
 |
|
 |
|
