24V 10A Power supply Item No.: ININ2409900   Features/ Functions Switching power supply 24V regulated output with low ripple Comply with CEC ,MEPS, EuP Certifications: UL, CUL, GS, CE, BS, SAA, RCM, PSE, CB, FCC, EMC, C-tick, RoHS      General Specifications Input :100-240VAC, 50/60Hz Output voltage : 24 VDC +/-5% Output current : 10A  Ripple : 240 mVp-p Max. Inrush current : Limited 15A for a cold start Dielectric withstand test: 5mA3000Vac for 2 seconds No load standby power ≤0.5W Efficiency: 90% Min.  Power factor correction(PFC): 0.9 Min. Temperature: Case 75 ℃ Max. Operating temperature: -29℃～+45.5℃ Storage temperature: -40℃～+75℃ Operating relative humidity: 5%～95% RH Over load protection: Auto recovery Short circuit protection: Auto recovery MTBF: 30000 hours full rated load operation at 25℃ AQL: MIL-STD-105D II AQL:CRI 0; MAJ 0.25; MIN 2.5 Warranty: 3 year FL5, No.62, Liusha S. RD., Shijie,Dongguan, Guangdong 523303 China 广东省东莞市石碣镇刘沙南路62号5层 Tel：+86(0)769-81812289 Fax：+86(0)769-81812989 E-mail: william@intaia.com Website: Http://www.intaia.com
