Battery charger for 12 volt SLA battery
Item No.: IN1500500
  Features/ Functions
  • Smart 3 stage charger
  • Continuously monitor battery voltage
  • Constant charging current
  • Terminate the charge once battery is full
  • Dual color LED indicate the charge status
  • Safety standard approvals: UL, CUL, PSE, CB, FCC
  •
      General Specifications
  • Input :100-240VAC, 50/60Hz
  • Output voltage : 9~14.6VDC
  • Output current : 0.5A+/-5%
  • Inrush current : Limited 15A for a cold start
  • No load standby power ≤0.5W
  • Efficiency: 80% Min.
  • Temperature: Case 65 ℃ Max.
  • Operating temperature: -29℃ ~+45.5℃
  • Storage temperature: -40℃ ~+75℃
  • Operating relative humidity: 5%~95% RH
  • Over load protection: Auto recovery
  • Short-circuit protection: Auto recovery
  • MTBF: 30000 hours full rated load operation at 35℃
  • AQL: MIL-STD-105D II CRI 0; MAJ 0.25; MIN 2.5
  • Warranty: 3 year
