Interchangeable plug power supply 12V 1.5A |
Item No.: IN1201500 |
|
|
Features/ Functions |
12V 1.5A power supply regulated output with low ripple
Interchaneable Euro/UK/USA/AU/JP mianis plugs
With a power-on LED indicator
Comply with CEC,ErP,MEPS regulations
Certifications: UL, cUL, GS, CE, RCM, PSE, CB |
|
|
|
 |
|
|
General Specifications |
Input :100-240VAC, 50/60Hz
Output voltage : 12 VDC +/-5%
Output current : 1.5A
Ripple : 120 mVp-p Max.
Inrush current : Limited 15A for a cold start
No load standby power ≤0.5W
Efficiency: 80 % Min.
Operating temperature: -29℃~+45.5℃
Storage temperature: -40℃~+75℃
Operating relative humidity: 5%~95% RH
Over load protection: Auto recovery
Short circuit protection: Auto recovery
MTBF: 30000 hours full rated load operation at 25℃
AQL: MIL-STD-105D II AQL:CRI 0; MAJ 0.25; MIN 2.5
|
|
|

 |
|
 |
|
