| DC 12V-24V input car charger 12.6V 3A for li-ion |
| Item No.: IN1263000 |
|
|
| Features/ Functions |
|
Including a standard cigarette lighter plug to receive power from truck, boat, car and more
Charging 3S cell Li-ion battery pack
Fully aotumatic without intervention
Terminating charge once battery pack is full
Dual color LED indicating charging status
Standard approvals: FCC, CE, RoHS
|
|
 |
|
|
| General Specifications |
- Input voltage :10~40VDC
- Output voltage : 8 ～ 12.6 VDC
- Output current : 3A +/-5%
- Inrush current : Limited 15A for a cold start
- No load standby power ≤0.5W
- Efficiency: 85% Min.
- Operating temperature: -29℃～+45.5℃
- Storage temperature: -40℃～+75℃
- Operating relative humidity: 5%～95% RH
- Over load protection: Auto recovery
- Short circuit protection: Auto recovery
- MTBF: 30000 hours full rated load operation at 25℃
- Inspection: MIL-STD-105D II AQL:CRI 0; MAJ 0.25; MIN 2.5
- Warranty: 3 year
|
|
|
 |
|
 |
|
