16.8v 5a UL GS lithium polymer battery charger
Item No.: IN1685000
  Features/ Functions
  • Charging 4S cell Lithium polymer battery pack
  • Fully aotumatic without intervention
  • Constant charge current /voltage
  • Terminating charging once battery pack is full
  • LED indicate the charge status
  • Safety standard approvals: UL, CUL, GS, CE, BS, RCM, PSE, CB, FCC, EMC, C-tick
  •
      General Specifications
  • Input :100-240VAC, 50/60Hz
  • Output voltage : 10~16.8 VDC
  • Output current : 5A +/-5%
  • Inrush current : Limited 15A for a cold start
  • No load standby power ≤0.5W
  • Efficiency: 85% Min.
  • Operating temperature: -29℃~+45.5℃
  • Storage temperature: -40℃~+75℃
  • Operating relative humidity: 5%~95% RH
  • Over load protection: Auto recovery
  • Short circuit protection: Auto recovery
  • MTBF: 30000 hours full rated load operation at 35℃
  • AQL: MIL-STD-105D II CRI 0; MAJ 0.25; MIN 2.5
