| MCU charger 15V 0.3A for 1100mAH NiMh battery |
| Item No.: IN1500300 |
|
|
| Features/ Functions |
|
MCU controls the whole charge process for 12V nimh battery
Automatic detection of shorted/ bad battery
4 hour charger timer
LED indicate the charge status
Safety standard approvals: GS, CE, EMC |
|
|
|
 |
|
|
| General Specifications |
- Input :100-240VAC, 50/60Hz
- Output voltage : 7.5 ～14.6VDC
- Output current : 0.3A +/-0.1A
- Inrush current : Limited 15A for a cold start
- No load standby power ≤0.5W
- Efficiency: 80% Min.
- Operating temperature: -29℃～+45.5℃
- Storage temperature: -40℃～+75℃
- Operating relative humidity: 5%～95% RH
- Over load protection: Auto recovery
- Short circuit protection: Auto recovery
- MTBF: 30000 hours full rated load operation at 35℃
- Application: for 10S cell Ni-mh battery pack
- Inspection: MIL-STD-105D II AQL:CRI 0; MAJ 0.25; MIN 2.5
- Warranty: 3 year
|
|
|
 |
|
 |
|
