| UL CE RCM PSE BS approved 12V 5A power adapter |
| Item No.: IN1205000 |
|
|
| Features/ Functions |
|
Top quality & high reliability
Comply with CEC,MEPS,EuP
Comply with FCC Part15 Class B
Certifications: UL, CUL, GS, CE, BS, SAA, PSE, CB, FCC, EMC, C-tick, RoHS
|
|
 |
|
|
| General Specifications |
- Input :100-240VAC, 50/60Hz
- Output voltage : 12VDC +/-5%
- Output current : 5A
- Ripple : 200 mVp-p Max.
- Inrush current : Limited 15A for a cold start
- No load standby power ≤0.5W
- Efficiency: 85 % Min.
- Operating temperature: -29℃～+45.5℃
- Storage temperature: -40℃～+75℃
- Operating relative humidity: 5%～95% RH
- Over load protection: Auto recovery
- Short circuit protection: Auto recovery
- MTBF: 30000 hours full rated load at 25℃
- AQL: MIL-STD-105D II AQL:CRI 0; MAJ 0.25; MIN 2.5
- Warranty: 3 year
|
|
|
 |
|
 |
|
