54.6V 2A bicycle 48V Lithium-ion battery charger
Item No.: IN550200
  Features/ Functions
  • Smart charger for 3.7 * 13S cell Li-ion battery pack
  • Continuously monitor battery voltage
  • Constant charging current /Voltage
  • Terminate the charge once battery is full
  • LED indicate the charge status
  • Safety standard approvals: UL, CUL, GS, CE, BS, RCM, PSE, CB, FCC, EMC, C-tick
  • 3 years warranty



  •
      General Specifications
  • Input :100-240VAC, 50/60Hz
  • Output voltage : 32~ 54.6VDC
  • Output current : 2A+/-5%
  • Inrush current : Limited 15A for a cold start
  • No load standby power ≤0.5W
  • Efficiency: 88% Min.
  • Temperature: Case 75 ℃ Max.
  • Operating temperature: -20℃ ~ +45℃
  • Storage temperature: -40℃ ~ +75℃
  • Operating relative humidity: 5%~95% RH
  • Over load protection: Auto recovery
  • Short-circuit protection: Auto recovery
  • MTBF: 40000 hours full rated load operation at 25℃
