Sealed Lead Acid 12V battery charger GS/CE
Item No.: IN1500500
  Features/ Functions

  • Compact, light and engineered for enhanced safe charging

  • 3 step charger fits for sealed lead acid applications

  • Constant charge current/ voltage

  • Terminte the charge once battery is full

  • Dual color LED didincate the charge stauts

  • Safety sandard approvals: GS, CE, EMC

    •


      General Specifications
  • Input :100-240VAC, 50/60Hz
  • Output voltage : 9～14.6VDC
  • Output current : 0.5A+/-5%
  • Floating charge voltage: 13.8V
  • Inrush current : Limited 15A for a cold start
  • No load standby power ≤0.5W
  • Efficiency: 80% Min.
  • Temperature: Case 65 ℃ Max.
  • Operating temperature: -29℃ ～+45.5℃
  • Storage temperature: -40℃ ～+75℃
  • Operating relative humidity: 5%～95% RH
  • Over load protection: Auto recovery
  • Short-circuit protection: Auto recovery
  • MTBF: 30000 hours full rated load operation at 35℃
  • AQL: MIL-STD-105D II CRI 0; MAJ 0.25; MIN 2.5
  • Warranty: 3 year
    		•
