12.6V 2A 3S lithium polymer /lipo battery charger
Item No.: IN1262000
Features/ Functions
Standard CC, CV and float charging
Terminate charge once battery is full
LED indicate the charge status
Standard approvals: UL CUL PSE FCC
General Specifications
Input :100-240VAC, 50/60Hz
Output voltage : 7.5~12.6Vdc
Output current : 2A+/-0.2
No load standby power ≤0.5W
Efficiency: 80% Min.
Operating temperature: -29℃~+45.5℃
Storage temperature: -40℃~+75℃
Operating relative humidity: 5%~95% RH
Over load protection: Auto recovery
Short circuit protection: Auto recovery
MTBF: 30000 hours full rated load operation at 25℃
Inspection: MIL-STD-105D II AQL:CRI 0; MAJ 0.25; MIN 2.5
Warranty: 3 year
