| 12.6V 7A Lithium Battery Charger Li-ion charger |
| Item No.: IN1267000 |
|
|
| Features/ Functions |
- Smart 12.6V Li-ion battery charger for 3 series cell pack
- Constant charge current
- Terminate the charge once battery is full
- With a dual color LED indicator
- Safety standard approvals: PSE, UL, CUL, PSE, RCM, FCC, EMC, T-tick
|
|
 |
|
|
| General Specifications |
|
Input :100-240VAC, 50/60Hz
Output voltage: 8～12.6VDC
Output current: 7A+/-10%
Inrush current : Limited 15A for a cold start
No load standby power ≤0.5W
Efficiency: 85% Min.
Temperature: Case 65 ℃ Max.
Operating temperature: -29℃ ～ +45.5℃
Storage temperature: -40℃ ～ +75℃
Operating relative humidity: 5%～95% RH
Over load protection: Auto recovery
Short-circuit protection: Auto recovery
MTBF: 30000 hours full rated load at 25℃
AQL: MIL-STD-105D II CRI 0; MAJ 0.25; MIN 2.5
Warranty: 3 year
|
|
|
 |
|
 |
|
