4S LiFePO4 battery Charger 14.8V 1.5A with UL PSE |
Item No.: IN1501500 |
|
|
Features/ Functions |
3-step charging control(pre-charge-CC-CV)Constant charging current
Terminating the charge once battery is full
Dual color LED indicator for charging status
Safety standard approvals: UL, CUL, PSE, CB, FCC
|
|
 |
|
|
General Specifications |
Input :100-240VAC, 50/60Hz
Output voltage : 8~14.8 VDC
Output current : 1.5A +/-100mA
Inrush current : Limited 15A for a cold start
No load standby power ≤0.5W
Efficiency: 80 % Min.
Temperature: Case 75 ℃ Max.
Operating temperature: -29℃ ~ +45.5℃
Storage temperature: -40℃ ~ +75℃
Operating relative humidity: 5%~95% RH
Over load protection: Auto recovery
Short-circuit protection: Auto recovery
MTBF: 30000 hours full rated load at 25℃
AQL: MIL-STD-105D II CRI 0; MAJ 0.25; MIN 2.5
Warranty: 3 year
|
|
|

 |
|
 |
|
