6V 3A ac/dc power supply with UL FCC certificated
Item No.: IN0603000
  Features/ Functions
  • Regulated output with low ripple
  • Power-on LED indicator
  • Comply with ErP regulations
  • Safety approval: UL, CUL, FCC
  • Warranty: 3 year
  •
      General Specifications
  • Input :100-240VAC, 50/60Hz
  • Output voltage : 6VDC
  • Output current: : 3A +/-5%
  • Ripple : 80 mVp-p Max.
  • Inrush current : Limited 15A for a cold start
  • No load standby power ≤0.5W
  • Efficiency: 70% Min.
  • Operating temperature: -29℃~+45.5℃
  • Storage temperature: -40℃~+75℃
  • Operating relative humidity: 5%~95% RH
  • Over load protection: Auto recovery
  • Short circuit protection: Auto recovery
  • MTBF: 30000 hours full rated load operation at 35℃
  • AQL: MIL-STD-105D II AQL:CRI 0; MAJ 0.25; MIN 2.5
