AC power adapter 9V 0.5A UL FCC certificated |
Item No.: IN0900500 |
|
|
Features/ Functions |
Regulated output with low ripple
Power-on LED indicator
Comply with ErP
Safety approval: UL, CUL, FCC |
|
|
|
 |
|
|
General Specifications |
Input :100-240VAC, 50/60Hz
Output voltage : 9VDC +/-5%
Output current: : 0.5A
Ripple : 100 mVp-p Max.
Inrush current : Limited 15A for a cold start
No load standby power ≤0.5W
Efficiency: 75% Min.
Operating temperature: -29℃~+45.5℃
Storage temperature: -40℃~+75℃
Operating relative humidity: 5%~95% RH
Over load protection: Auto recovery
Short circuit protection: Auto recovery
MTBF: 30000 hours full rated load operation at 25℃
AQL: MIL-STD-105D II CRI 0; MAJ 0.25; MIN 2.5
Warranty: 3 year
|
|
|

 |
|
 |
|
