| Electric bike battery charger 42 volts 7 amps |
| Item No.: IN4207000 |
|
|
| Features/ Functions |
|
High power battery charger desinged for E-bike with 10S Li-ion battery pack
Constant charging current /Voltage
Terminate charge once battery pack is full
A dual color LED indicate the charge status
Safety standard approvals: CE, FCC, EMC
|
|
 |
|
|
| General Specifications |
|
Input :100-240VAC, 50/60Hz
Output voltage : 25～42.5VDC
Output current : 7A+/-5%
Inrush current : Limited 15A for a cold start
No load standby power ≤0.5W
Efficiency: 88 % Min.
Temperature: Case 65 ℃ Max.
Operating temperature: -29℃ ～ +45.5℃
Storage temperature: -40℃ ～ +75℃
Operating relative humidity: 5%～95% RH
Over load protection: Auto recovery
Short-circuit protection: Auto recovery
MTBF: 30000 hours full rated load at 25℃
Warranty: 2 year
|
|
|
 |
|
 |
|
