Batttery charger 73V 6A for 60V E-bike battery
Item No.: IN7306000
  Features/ Functions
  • High power battery charger desinged for E-bike with 6S Lead acid battery pack
  • Constant charging current /Voltage
  • Terminate charge once battery pack is full
  •  A dual color LED indicate the charge status
  • Safety standard approvals: CE, FCC, EMC
  •
      General Specifications
  • Input :100-240VAC, 50/60Hz
  • Output voltage : 50~73.5VDC
  • Output current : 6A+/-5%
  • Inrush current : Limited 15A for a cold start
  • No load standby power ≤0.5W
  • Efficiency: 90% Min.
  • Temperature: Case 65 ℃ Max.
  • Operating temperature: -29℃ ~+45.5℃
  • Storage temperature: -40℃ ~+75℃
  • Operating relative humidity: 5%~95% RH
  • Over load protection: Auto recovery
  • Short-circuit protection: Auto recovery
  • MTBF: 30000 hours full rated load at 25℃
  • Warranty: 2 year
