| Automatic 6V/12V Lead acid battery charger |
| Item No.: IN1501000 |
|
|
| Features/ Functions |
|
This charger is intelligent, easy to use, safe and low costs. It is designed to charge motorcycles, cars, boats, RVs, tractors and equipment that are not used for some time. It is for 6V and 12V batteries and does not need to manually switch between 6V and 12V.
Automatically identifies the battery voltage 6V or 12V and adjusts itself to correct charging voltage/current needs
3 stage battery charger with constant current, constant voltage and drops to a float charge when the battery is full so it can be left connected for long periods of time without the worry of overcharging the battery.
Output cable with crocodile clamps
Protection against short-sircuit and reverse connect
Dule color LED indicator for charging status
Safety standard approvals: GS, CE, EMC |
|
|
|
|
 |
|
|
| General Specifications |
|
Input :100-240VAC, 50/60Hz
Output voltage : 4～7.5VDC, 9~14.8VDC
Output current : 1A+/-0.1A
Inrush current : Limited 15A for a cold start
No load standby power ≤0.5W
Efficiency: 80% Min.
Temperature: Case 75 ℃ Max.
Operating temperature: -29℃ ～ +45.5℃
Storage temperature: -40℃ ～ +75℃
Operating relative humidity: 5%～95% RH
Over load protection: Auto recovery
Short-circuit protection: Auto recovery
MTBF: 30000 hours full rated load at 35℃
AQL: MIL-STD-105D II CRI 0; MAJ 0.25; MIN 2.5
Warranty : 3 year
|
|
|
 |
|
 |
|
