| 29.4V 5A Lithium battery charger for 7S 24V cell |
| Item No.: IN2905000 |
|
|
| Features/ Functions |
|
- 150W 3 statge Li-ion battery charger
- Worldwide AC input voltage
- Terminate the charge once battery is full
- With a dual color LED indicator
- Safety standard approvals: PSE, UL, CUL, PSE, RCM, FCC, EMC, T-tick
|
|
 |
|
|
| General Specifications |
|
|
INPUT |
|
Input Voltage |
85-264VAC |
|
Input Frequency |
47-60Hz |
|
Input Current |
0.8A Max at 110VAC |
|
Inrush Current |
40A Max at 230VAC |
|
Earth Leakage Current |
Class II |
|
No Load Input Power |
<0.3W |
|
OUTPUT |
|
Output Voltage |
18~29.4V |
|
Output Current |
5A+/-5% |
|
Efficiency |
>95% |
|
Start Up Delay |
1.3s Max |
|
Start Up Rise Time |
15ms Typical |
|
Hold Up Time |
10ms Min at full load 115VAC |
|
Line Regulation |
+/-1% Max |
|
Load Regulation |
+/-5% Max |
|
Ripple Noise |
1% Max |
|
Over voltage Protection |
150% Of Nominal Output |
|
Over current Protection |
Constant current 5A Max |
|
Short Circuit Protection |
Trip And Restart |
|
ENVIRONMENT |
|
Isolation |
3000VAC Input To Output |
|
MTBF |
3000 hours full load at 25℃ |
|
Operation Temperature |
-29～+45.5℃ |
|
Cooling |
Natural Convection |
|
Operating Humidity |
5% To 90% RH,Non-Condensing |
|
Storage Temperature |
-40~+75℃ |
|
Shock |
30g,Half Sine,6 Axes |
|
Vibration |
5-50Hz,Accelerated 7.35m/s |
|
Altitude |
3000m |
|
|
|
 |
|
 |
|
