MCU controls the whole charge process and guarantees the battery pack is fully charged, and also avoids battery pack over charge.
Automatic detection of shorted/ bad battery
Use of 3 termination methods
- Charge terminates when voltage drop (-dV/dt) is detected. - Charge terminates when the voltage rises above 16.5V. - Charge terminates when the timer is up to 7 hours.
LED indicate the charge status
Safety standard approvals: GS, CE, EMC, RoHS
For 2000mAH (3 x aaa cell) 3.6V ni-mh battery pack
General Specifications
Input :100-240VAC, 50/60Hz
Output voltage : 2.4~4.5VDC
Output current: 0.3A
Inrush current : Limited 15A for a cold start
No load standby power ≤0.2W
Efficiency: 60%
Operating temperature: -29℃ ~+45.5℃
Storage temperature: -40℃ ~+75℃
Operating relative humidity: 5% ~ 95% RH
Over load protection: Auto recovery
Short circuit protection: Auto recovery
MTBF: 30000 hours full rated load operation at 25℃
Inspection: MIL-STD-105D II AQL:CRI 0; MAJ 0.25; MIN 2.5
Warranty: 3 year
