3S 18650 Lithium ion battery charger 16.8V 1A PSE
Item No.: IN1681000
  Features/ Functions
  • 3 stage smart charger
  • Constant charging current /Voltage
  • Stopping charge once battery is full
  • With a dual color LED indicator
  • Safety standard approvals: UL, cUL, PSE, FCC
  •
      General Specifications
  • Input :100-240VAC, 50/60Hz
  • Output voltage : 10~16.8VDC
  • Output current : 1A +/-0.1A
  • Inrush current : Limited 30A for a cold start
  • No load standby power ≤0.5W
  • Efficiency: 85% Min.
  • Operating temperature: -29℃~+45.5℃
  • Storage temperature: -40℃~+75℃
  • Operating relative humidity: 5%~95% RH
  • Over load protection: Auto recovery
  • Short circuit protection: Auto recovery
  • MTBF: 30000 hours full rated load operation at 25℃
  • Inspection: MIL-STD-105D II AQL:CRI 0; MAJ 0.25; MIN 2.5
  • Warranty : 3 year






  • FL5, No.62, Liusha S. RD., Shijie,Dongguan, Guangdong 523303 China 广东省东莞市石碣镇刘沙南路62号5层
    Tel:+86(0)769-81812289 Fax:+86(0)769-81812989 E-mail: william@intaia.com Website: Http://www.intaia.com
