Battery charger for 12V130AH Lead acid battery
Item No.: IN15012000
  Features/ Functions
  • Automatic battery charger for 12v 130ah lead acid battery
  • Constant current and voltage (CC,CV mode)
  • Stop charging when the battery is full
  • LED indicating charging status
  • Safety standard: UL, CE, FCC
    •
      General Specifications
  • Input :100-240VAC, 50/60Hz
  • Charging voltage : 9 ～14.6VDC
  • Charging current : 12A +/-5%
  • Inrush current : Limited 30A for a cold start
  • No load standby power ≤0.8W
  • Efficiency: 90% Min.
  • Operating temperature: -20℃ ～+40℃
  • Storage temperature: -40℃ ～+75℃
  • Operating relative humidity: 5%～95% RH
  • Over load protection: Auto recovery
  • Short circuit protection: Auto recovery
  • MTBF: 30000 hours full rated load operation at 25℃
