| 42V5A DC output li-ion battery charger |
| Item No.: IN4255000 |
|
|
| Features/ Functions |
|
3-stage charging mode: CC(constant current), CV(constant voltage) and float stage
Stop charging when the battery is full
2 color LED indicating charging status
Safety standard approvals: UL, CUL, CE, PSE, CB, FCC+
Warranty: 3 year
|
|
 |
|
|
| General Specifications |
|
Input :100-240VAC, 50/60Hz
Output voltage : 25 ～42.5VDC
Output current : 5A +/-5%
Inrush current : Limited 15A for a cold start
No load standby power ≤0.5W
Efficiency: 90% Min.
Operating temperature: -29℃ ～+45.5℃
Storage temperature: -40℃ ～+75℃
Operating relative humidity: 5%～95% RH
Over load protection: Auto recovery
Short circuit protection: Auto recovery
MTBF: 30000 hours full rated load operation at 25℃
Inspection: MIL-STD-105D II AQL:CRI 0; MAJ 0.25; MIN 2.5
Specification
|
Nominal
Voltage |
CV |
CC |
Net Weight |
|
Lead Acid |
Li-MnO2 |
LiFePO4 |
A |
(kg) |
|
12V |
14.7V |
16.8V |
14.6V |
10 |
1.0 |
|
24V |
29.4V |
29.4V |
29.2V |
7 |
|
36V |
44.1V |
42.0V |
43.8V |
4.8 |
|
48V |
58.8V |
54.6V |
58.4V |
3.8 |
|
|
|
 |
|
 |
|
