SAA C-tick RCM certified Li-ion charger 16.8V 2A |
Item No.: IN1682000 |
|
|
Features/ Functions |
The IN1682000 is designed to charge 4S cell Li-ion battery pack. This charger is easy and safe to use. It features pre-charging, bad/wrong battery indentification and alarm, backfeed protection(BFP), anit reverse polarity connection, eliminating sparks by soft start. It has been certified for the safety standards including UL1310 Class 2 Battery Charger, EN/AS/NZS60335-1/ 2-29 Household and similar electrical appliances - Particular requirements for battery chargers.
|
|
 |
|
|
General Specifications |
Input :100-240VAC, 50/60Hz
Output voltage : 10 ~ 16.8VDC
Output current : 2A +/-0.3A
Inrush current : Limited 30A for a cold start
No load standby power ≤0.5W
Efficiency: 85% Min.
Operating temperature: -10℃~+45.5℃
Storage temperature: -40℃~+75℃
Operating relative humidity: 5%~95% RH
MTBF: 30000 hours full rated load operation at 25℃
Warranty : 3 year
|
|
|

 |
|
 |
|
