li-ion battery charger 12.6V1A UL cUL listed
Item No.: IN1261000
  Features/ Functions
  • Smart Li-ion battery charger for 3 series cell pack
  • Constant charge current / voltage
  • Terminate the charge once battery is full
  • With a dual color LED indicator
  • Safety standard approvals: PSE, UL, CUL, CB, FCC

  General Specifications
  • Input :100-240VAC, 50/60Hz
  • Output voltage: 7.5~12.6VDC
  • Output current: 1A+/-10%
  • Inrush current : Limited 15A for a cold start
  • No load standby power ≤0.5W
  • Efficiency: 80 % Min.
  • Temperature: Case 65 ℃ Max.
  • Operating temperature: -20℃ ~ +45.5℃
  • Storage temperature: -40℃ ~ +75℃
  • Operating relative humidity: 5%~95% RH
  • Over load protection: Auto recovery
  • Short-circuit protection: Auto recovery
  • MTBF: 30000 hours full rated load at 25℃
  • Warranty: 3 year
