12V 100W power supply 12V 7.5A with UL/CE rating |
Item No.: IN1207000 |
|
|
Features/ Functions |
Universal AC input
Regulated output with low ripple
Active power factor correction
Certifications: UL, CUL, GS, CE, BS, SAA, EK, PSE, CB, FCC, EMC, C-tick, RoHS
CEC/DOE/EuP/EMPS energy efficiency Level VI
Warranty: 3 year
|
|
 |
|
|
General Specifications |
Input :100-240VAC, 50/60Hz
Output voltage : 12VDC +/-5%
Output current : 7.5A
Ripple : 250 mVp-p Max.
Inrush current : Limited 15A for a cold start
Dielectric withstand test: 5mA3000Vac for 2 seconds
No load standby power ≤0.21W
Efficiency: 89% Min.
Power factor: >0.95
Temperature: Case 75 ℃ Max.
Operating temperature: -29℃~+45.5℃
Storage temperature: -40℃~+75℃
Operating relative humidity: 5%~95% RH
Over load protection: Auto recovery
Short circuit protection: Auto recovery
MTBF: 30000 hours full rated load operation at 25℃
|
|
|

 |
|
 |
|
