AC DC adapter 36v 3A with power factor correction
Item No.: IN3603000
  Features/ Functions
  • Regulated output with low ripple
  • Strong load capability
  • Power factor correction
  • Safety certified to UL, CUL, GS, CE, BS, SAA, EK, PSE, CB, FCC, EMC, C-tick, RoHS
  • Warranty: 3 year
  •
      General Specifications
  • Input :100-240VAC, 50/60Hz
  • Output voltage : 36 VDC +/-5%
  • Output current : 3A
  • Ripple : 400 mVp-p Max.
  • Inrush current : Limited 15A for a cold start
  • No load standby power ≤0.5W
  • Power factor: > 0.9
  • Efficiency: 85 % Min.
  • Operating temperature: -29℃~+45.5℃
  • Storage temperature: -40℃~+75℃
  • Operating relative humidity: 5%~95% RH
  • Over load protection: Auto recovery
  • Short circuit protection: Auto recovery
  • MTBF: 30000 hours full rated load operation at 25℃
