AC power adapter 9.5V 1A with exchangeable plugs |
Item No.: IN1001000 |
|
|
Features/ Functions |
Universal input voltage
Exchangeable plug available USA EU JP AU UK
Meets EMPS/DOE/EUP energy efficiency level VI
Certifications: UL, CUL, GS, CE, BS, SAA, EK, PSE, CB, FCC, EMC, C-tick, RoHS
|
|
 |
|
|
General Specifications |
Input :100-240VAC, 50/60Hz
Output voltage : 9.5VDC +/-5%
Output current : 1A
Ripple : 200 mVp-p Max.
Inrush current : Limited 15A for a cold start
No load standby power ≤0.1W
Efficiency: 90% the Min.
Dlelectric withstand test: 5mA 3000VAC
Operating temperature: -29℃ ~+45.5℃
Storage temperature: -40℃ ~+75℃
Operating relative humidity: 5%~95% RH
Over load protection: Auto recovery
Short circuit protection: Auto recovery
MTBF: 30000 hours full rated load operation at 25℃
Warranty: 3 year
|
|
|

 |
|
 |
|
