| AC DC switching power supply 12V6A |
| Item No.: IN1206000 |
|
|
| Features/ Functions |
|
Power supply switching 12V 6A regulated output with low ripple
With a power-on LED indicator
Comply with CEC,MEPS,EuP Level VI
Certifications: UL, CUL, GS, CE, BS, SAA, EK, PSE, CB, FCC, EMC, C-tick, RoHS
Warranty: 3 years
|
|
 |
|
|
| General Specifications |
- Input :100-240VAC, 50/60Hz
- Output voltage : 12 VDC +/-5%
- Output current : 6A
- Ripple: 120 mVp-p Max.
- Inrush current : Limited 15A for a cold start
- No load standby power ≤0.21W
- Efficiency: 90 % Min.
- Operating temperature: -29℃～+45.5℃
- Storage temperature: -40℃～+75℃
- Operating relative humidity: 5%～95% RH
- Over load protection: Auto recovery
- Short circuit protection: Auto recovery
- MTBF: 30000 hours full rated load at 25℃
|
|
|
 |
|
 |
|
