Mini USB charger UL approved
Item No.: IN0501000
  Features/ Functions
  • Regulated output with low ripple
  • Power-on LED indicator
  • Comply with ENERGY STAR
  • Safety standard approvals: UL, cUL, PSE, FCC, RoHS




  General Specifications
  • Input :100-240VAC, 50/60Hz
  • Output voltage : 5 VDC +/-5%
  • Output current : 1A
  • Ripple : 50mVp-p Max.
  • Inrush current : Limited 15A for a cold start
  • No load standby power ≤0.5W
  • Efficiency: 75% Min.
  • Operating temperature: -29℃~+45.5℃
  • Storage temperature: -40℃~+75℃
  • Operating relative humidity:5%~95%RH
  • Over load protection: Auto recovery
  • Short circuit protection: Auto recovery
  • MTBF: 30000 hours full rated load operation at 25℃
  • AQL: MIL-STD-105D II AQL:CRI 0; MAJ 0.25; MIN 2.5
  • Warranty: 3 year
