This AC DC adapter 12V 3A is built with the latest power supply technologies and the quality components materials to enable high performance. It features resonant-ring valley-switching operation for high operating efficiency, green-mode power-saving operation to achieve excellent energy efficiency performance. The AC DC adapter 12V output provides both constant voltage regulation and over-current protection. The ac/dc adapter provides excellent EMI performance working at 80-kHz Maximum switching Frequency, with fault protections to maximize the reliability. Effective natural cooling thermal management enhances operating performance and reliability, enables the AC DC power adapter 12V 3A to operate at full power at higher ambient temperatures.

This wall mounted power adapter 5V 2A provides a high-power-density and cost-effective solution for a variety of application field. The 5V 2A power adapter operates at a high switching frequency to achieve high efficiency in all load conditions, with a low total standby consumption and low output ripple and noise. Full protection functions improve the reliability including OCP, OVP, OLP, and effective thermal management enhances reliability further, allows the 5V 2A power supply to operate at full power in higher ambient temperatures. See more our wall type 5V power adapters for power adapter 5V 1A and power adapter 5V 2500mA.

This AC power adapter AC to 9V 1500mA employs latest technologies to achieve excellent regulation, high power density and safety with good EMC performance. The primary side regulation (PSR) 9 Volt AC power adapter can provide accurate constant current (CC) regulation without optocoupler and secondary control circuitry to enable low standby power consumption and cost effective solution. The 9V AC power adapter comes with exchangeable AC plugs optional for EU, US, AU, UK, JP, CN outlets for worldwide travel. The AC power adapter AC to 9vdc 1.5 amp as well as 9V 2.5 amp AC adapter meet all green energy initiatives and offers a wide range of safety features including over-current protection, over-load protection, short-circuit protection to prevent the circuit from being damaged in abnormal conditions.

This ac power adapter 12V 3A employs latest technologies to achieve excellent regulation, high power density and safety with good EMI performance. The universal 12V 3A power adapter provides high conversion efficiency, high PF and low total harmonic distortion (THD) over the universal input voltage. The AC/DC power adapter 12V is flyback topology based with green-mode power-saving operation, enables low standby power and compact design. The ac adapter output 12V 3A provides both constant voltage regulation and over-current protection. The 12V 3A power adapter features multiple protection functions to guarantee safe operation and reliability including OCP,OVP,OLP..

The fuyuan fy2405000 switching power supply 24V 5A employs latest technologies to achieve excellent regulation, high power density and safety with good EMI performance. Flyback topology based with green-mode power-saving operation enables low standby power and compact profile. The power adapter 24V 5A is designed to ensure a MTBF better than 40000 hours at 25℃ full load. It incorporates a pair of U shaped internal heat sinks to achieve efficient natural convection cooling that enables higher operating temperatures and reliability. The FY2405000 power supply is safety certified to IEC/UL/EN 60950-1 and carries the CE mark for the Low Voltage and RoHS Directives. The series is also compliant to EN 55022-B and FCC Class B for radiated and conducted emissions and the IEC 61000-4 immunity and IEC 61000-3-2 harmonic current standards. Found out more for product availability for the FY2404000, FY1202000, FY1205000...

This 48V 2.5A switching power adapter is built with the latest power supply technologies and the quality components materials to enable high performance. High-frequency AC-to-DC flyback converter with green-mode power-saving operation enables high power density and lowest no-load power consumption, to comply with global efficiency standards including DoE Level VI and EU CoC V5 Tier-2. The 48V 2.5A power adapter features full protection to maximize the reliability. These features include OLP(Over Load Protection), OVP(Over Voltage Protection), output short-circuit protection. The 48V power adapter incorporates a pair of U shaped internal heat sinks to achieve efficient natural convection cooling to enable higher operating temperatures and reliability. The 48 volt power adapter series is safety certified to IEC/UL/EN 60950-1 and carries the CE mark for the Low Voltage and RoHS Directives. The 48V adapter series is also compliant to EN 55022-B and FCC Class B for radiated and conducted emissions and the IEC 61000-4 immunity and IEC 61000-3-2 harmonic current standards.

This power adapter 24V 4A is built with the latest power supply technologies and the quality components materials to enable high performance. The 24 volt AC DC adapter features 80-kHz Maximum Switching Frequency, Resonant-Ring Valley-Switching Operation for High operating efficiency, Green-mode Power-Saving Operation, Opto-Coupled Feedback Enables up to 2% Regulation. The ac dc adapter 24vdc is designed to ensure a MTBF better than 40000 hours at 25℃ full load. To maximize the reliability, the 24 volt DC adapter has fault protections including Output Over-Voltage, Over-Current, Short-Circuit protections. The AC DC adapter 24 volt series is safety certified to IEC/UL/EN 60950-1 and carries the CE mark for the Low Voltage and RoHS2 Directives. The 24V AC DC adapter series is also compliant to EN 55022-B and FCC Class B for radiated and conducted emissions and the IEC 61000-4 immunity and IEC 61000-3-2 harmonic current standards.

This efficient 18V 2A power adapter employs an isolated-flyback power-supply controller that provides Constant-Voltage (CV) using an optical coupler to improve transient response to large-load steps. The 18V adatper processes information from opto-coupled feedback and an auxiliary flyback winding for high-performance control of output voltage and current. The output voltage is regulated accurately by a high-performance voltage-mode amplifier with an accurate voltage reference. The switching adapter meets all green energy initiatives and enables excellent energy efficiency performance with compact profile. The flypower switching adapter offers a wide range of safety features including over-current protection, over-load protection, short-circuit protection to enhance reliability. Equipped with Effective thermal management, the 18V adapter is designed to a MTBF better than 40000 hours at 25℃ with full load. The 18V power adapter series is safety certified to IEC/UL/CSA/EN/RCM/J 60950-1 and carries the CE mark for the Low Voltage and RoHS Directives. The switching adapter PSE is also compliant to EN 55022-B and FCC Class B for radiated and conducted emissions and the IEC 61000-4 immunity and IEC 61000-3-2 harmonic current standards.

This wall mounted switching adapter 15V 18W provides a high-power-density and cost-effective solution for a variety of application field. The 15vdc adapter operates at a high switching frequency to achieve high efficiency in all load conditions, with a low total standby consumption and low output ripple and noise. The 15 volt AC DC adapter features excellent EMC performance. It is designed to ensure a MTBF better than 40000 hours at full load. The AC adapter 15V 1A is equipped with full protection functions to improve the reliability including OCP, OVP, OLP, Effective thermal management enhances reliability further, allows the 15V power adapter to operate at full power at high ambient temperatures.

The 12V 1A power adapter employs latest technologies to achieve excellent regulation, high power density with good EMC performance. Flyback topology based with green-mode power-saving operation enables low standby power. The power adapter 12V 1A provides excellent regulation while using primary-sensing feedback to achieve cost effectiveness and high efficiency. The 12V 1A AC adapter features multiple protection functions to guarantee safe operation and reliability including OCP, OVP, OLP. The 12V 1A adapter is safety certified to IEC/UL/EN 60950-1 and carries the CE mark for the Low Voltage and RoHS Directives. The 12V power adapter 1A is also compliant to EN 55022-B and FCC Class B for radiated and conducted emissions and the IEC 61000-4 immunity and IEC 61000-3-2 harmonic current standards.

This 12V 4A power adapter employs latest technologies to achieve excellent regulation, high power density and safety with good EMI performance. The 12V 4A adapter will improve efficiency to a level of 88% and reduce power consumption at standby mode, thereby contributing to reduce environmental burden. The AC DC adapter 12V 4A comes with compact size, low noise and high reliability and supports various demands from highly precise measurement devices. The AC DC adapter 220V to 12V features multiple protection functions to guarantee safe operation and reliability including OCP,OVP,OLP.. The 12V 4A AC/DC adapter is backed by a 3-year warranty. The 12V AC power supply series is safety certified to IEC/UL/EN 60950-1 and carries the CE mark for the Low Voltage and RoHS Directives. The 12V series is also compliant to EN 55022-B and FCC Class B for radiated and conducted emissions and the IEC 61000-4 immunity and IEC 61000-3-2 harmonic current standards.

The universal power adapter 36V 3A employs latest technologies to achieve excellent regulation, high power density and safety with good EMI performance. Flyback topology based with green-mode power-saving operation, enable low standby power and compact profile. The AC DC adapter 36V features multiple protection functions to guarantee safe operation and reliability including OCP, OVP, OLP. The AC adapter 36V 3A incorporates a pair of U shaped internal heat sinks to achieve efficient natural convection cooling that enables higher operating temperatures and reliability. The 36V power adapter series is safety certified to IEC/UL/EN 60950-1 and carries the CE mark for the Low Voltage and RoHS Directives. The 36v adapter series is also compliant to EN 55022-B and FCC Class B for radiated and conducted emissions and the IEC 61000-4 immunity and IEC 61000-3-2 harmonic current standards.
